FH541V-DS01-S
1" X 80mm PTO, Electric Start, Charging Coil, Std.
Muffler (oil filter side), Separate choke and throttle
Replaces Model #'s:
FH500V-S00: AS00, BS00
FH500V-S05: AS05
FH500V-S07: AS07
FH500V-S16: AS16
FH541V-S01: AS01, BS01, CS01, DS01 FH541V-S10: AS10, BS10 FH541V-W00: AW00, BW00
OUR ITEM #
YOUR PRICE
BUY NOW
KAWFH541V-DS01-S
Engine is no longer
Available. For a replacement engine please see our
FH580V-DS01-S, all the same
Specifications but more 2 more HP or see our extensive line of
Kawasaki Rebuild Kits.
FH541V-ES20-S
1" X 80mm PTO, Electric Start, Charging Coil, Std.
Muffler, Separate choke and throttle, KAI Please note all engines listed below can be replaced with this
engine, this engine has the muffler on the oil filter side, if yours is on
the fuel pump side you may need to reuse your old muffler.This
engine also has a separate choke and throttle (not combined choke and
throttle)
Replaces Model #'s:
FH381V SPEC #'S:S01, AS01, BS01, CS01, DS01, S20, AS20,
BS20, CS20, DS20
FH430V SPEC #'S:S01, AS01, BS01, CS01, DS01, S04, AS04,
BS04, CS04, DS04, S05, AS05, BS05, CS05, S07, AS07, BS07,
S11, AS11, BS11, CS11, DS11, S16, AS16, BS16, CS16, DS16, S20,
AS20, BS20, CS20, DS20, S23, AS23, BS23, CS23, DS23, S37,
AS37, BS37, CS37, S38, AS38, BS38, S41, AS41, S51, AS51,
AS51
FH451V SPEC #'S: W00, AS01, BS01, CS01, AS06, AS10,
BS10, AS15, BS15, AS16, BS16, AS17, BS17, CS17, DS17,
AS18, BS18, CS18, AS20, BS20, CS20, AS20, BS20, CS20
FH480V SPEC #'S: AS01, BS01, AS20, BS20, CS20, DS20, AS50, W00
FH500V SPEC #'S: AS01, BS01, AS10, BS10, CS10, DS10, ES10, FS10,
GS10, HS10, AS12, AS14, BS14, CS14, AS15, BS15,
AS19, AS21, AS23, AS24, AS26, AS30,
AS33, BS33, AS35, AS36, BS36, CS36, DS36, ES36, AS38,
AS40, AS43
FH531V SPEC #'S: AS05, BS05, AS06, BS06, AS07, BS07,
CS07, AS08, BS08, AS09, AS10, AS11
FH541V SPEC #'S: AS07, BS07, AS08, AS20, BS20, CS20, DS20, ES20,
AS24, BS24, CS24, DS24, ES24, AS25, BS25, CS25, DS25, AS27, BS27,
CS27, DS27, AS28, BS28, CS28, DS28, AS31, BS31, CS31, DS31, ES31, AS33, BS33, CS33, DS33, ES33, AS42, AS44, BS44, CS44, AS45, BS45, CS45, AS48, AS50, AS53,
W00
OUR ITEM #
YOUR PRICE
BUY NOW
KAWFH541V-ES20-S
Engine is no longer
Available. For a replacement engine please see our
FH580V-ES20-S, all the same
Specifications but more 2 more HP or see our extensive line of
Kawasaki Rebuild Kits.
FH541V-ES21-S
1" X 80mm PTO, Recoil Start, Clutch Coil, Std.
Muffler (oil filter side), Combined choke and throttle, KAI Please note all engines listed below can be replaced with this
engine, this engine has the muffler on the oil filter side, if yours is on
the fuel pump side you may need to reuse your old muffler.This engine also has a combined choke and throttle (not a
separate choke and throttle) Replaces Model #'s: FH381V SPEC #S: S07, AS07, BS07, CS07, DS07, ES07, S08,
AS08, BS08, CS08, S26, S27, AS27, BS27, CS27, S29, AS29,
S30, AS30
FH430V SPEC #'S: S02, S03, S06, S08, S10, S12, S14, S16, S24, S25, S26, S27,
S28, S29, S30, S33, S34, S35, S36, S39, S40, S53
FH451V SPEC #'S: S02, S03, S04, S05, S07, S08, S09, S11, S13, S14, S19,
FH480V SPEC #'S: S02, S03, S21, S22, S24,
FH500V SPEC #'S: S02, S03, S04, S06, S08, S09, S16, S17, S20, S25, S28, S29,
S31, S34, S42
FH541V-S21: AS21, BS21, CS21, DS21, ES21 FH541V-S23: AS23, BS23, CS23, DS23, ES23, FS23
FH541V-S29: AS29, BS29, CS29, DS29, ES29 FH541V-S30: AS30, BS30, CS30, DS30, ES30, FS30, GS30 FH541V-S32: AS32, BS32, CS32, DS32, ES32 FH541V-S34: AS34
FH541V-S38: AS38, BS38, CS38, DS38 FH541V-S40: AS40, BS40, CS40 FH541V-S43: AS43, BS43, CS43 FH541V-S46: AS46, BS46
OUR ITEM #
YOUR PRICE
BUY NOW
KAWFH541V-ES21-S
Engine is no longer
Available. For a replacement engine please see our
FH580V-ES21-S, all the same
Specifications but more 2 more HP or see our extensive line of
Kawasaki Rebuild Kits.
FH541V-ES22-S
1" X 80mm PTO, Recoil Start, Without Coil, Std.
Muffler (oil filter side), Combined choke and throttle, KAI (dual element
air filter) Please note all engines listed below can be replaced with this
engine, this engine has the muffler on the oil filter side, if yours is on
the fuel pump side you may need to reuse your old muffler.This engine also has a combined choke and throttle (not a
separate choke and throttle)
Replaces Model #'s:
FH381V SPEC #'S: S03, S05, S06, S12, S22, S23, S24, S25
FH430V SPEC #'S: S03, S08, S22, S25, S26
FH451V SPEC #'S: S03, S04
FH480V SPEC #'S: S03, S22
FH500V SPEC #'S: S03, S06, S08, S13, S34,
FH541V-S22: AS22, BS22, CS22, DS22, ES22 FH541V-S23: AS23, BS23, CS23, DS23, ES23, FS23
OUR ITEM #
YOUR PRICE
BUY NOW
KAWFH541V-ES22-S
Engine is no longer
Available. For a replacement engine please see our
FH580V-ES21-S, all the same
Specifications but more 2 more HP also comes with a charging coil, just dont
plug it in if not needed. Or see our extensive line of
Kawasaki Rebuild Kits.
